RAK13004 WisBlock PWM Expander Module PCA9685 PID: 100027
Product Description
RAK13004 is a PWM expansion module from WisBlock utilizing the NXP PCA9685 chip. It supports as many as 16 PWM pulse-width modulated outputs and can manage the brightness of 16 external LEDs.
Product Features
-
- 3.3V input voltage, on/off control by the WisBlock Core module
- 16 LED drivers connector
- 1 MHz Fast-mode Plus compatible I2C-bus interface
- 4096-step (12-bit) linear programmable brightness per LED.
- LED output frequency typically varies from 24Hz to 1526Hz
- Supports hot insertion
- Low Standby Current
- 5.5V tolerant inputs
- Operating Voltage: 2.3V to 5.5V @ -40Ā°C to +85Ā°C
- Module size: 25X35mm
Package Inclusion
- 1pc RAK13002Ā WisBlock IO Adapter Module
Documentation
- RAK13004 Quick Start Guide
- Datasheet
- WisBlock Quick Start Guide
- WisBlock Source Code Repository (opensĀ new window)
- RAK13004 3D Model (opensĀ new window)
- 40-Pin Male Connector 3D File (opens new window)
- WisBlock Sensor Tutorial
